VIDEPAK Product Guide to Polypropylene Woven Sacks: Valve, BOPP and Paper-Laminated Packaging Solutions

Industrial packaging has a simple job on paper: hold the product, protect it, move it, and present it. In real supply chains, however, that simple job becomes a demanding engineering task. A sack may move from a high-speed filling machine to a pallet, from a warehouse to a container, from a humid port to a dry distributor, and finally from a forklift to a retail or industrial customer. Strength matters. Moisture control matters. Filling speed matters. Print quality matters. And, increasingly, the package must deliver all of these benefits at the same time.

This is why VIDEPAK develops Polypropylene Woven Sacks, Polypropylene Woven Valve Sacks, BOPP Polypropylene Woven Sacks, and Paper Laminated Polypropylene Woven Sacks as packaging systems rather than simple bags. The basic woven polypropylene structure provides a strong mechanical foundation, while lamination, coating, liners, valves, perforation, surface treatments, printing and closure designs can be selected around the actual product and filling process. VIDEPAK’s published product range covers common capacities from about 5 kg to 50 kg for general PP woven packaging, with dimensions, fabric weight and structural features available for customization.

For foodstuffs such as cereals, sugar and pulses, woven polypropylene sacks are also covered by the scope of ISO 23560:2015 for 25 kg and 50 kg applications, illustrating how established this packaging structure is in dry-product logistics. Final specifications, of course, must always be matched to the product, local regulations, customer requirements and filling conditions rather than copied from a generic reference table.

Why Polypropylene Woven Sacks Remain the Core Industrial Packaging Platform

Polypropylene Woven Sacks begin with polypropylene tapes that are extruded, drawn and woven into a fabric. Drawing the tapes creates an oriented structure, while the woven warp-and-weft construction spreads loads across many individual tapes. The result is a lightweight textile-like package designed to provide tensile strength, resistance to tearing and puncture, and reliable performance during filling, lifting, stacking and transport. VIDEPAK describes its production route as resin preparation, tape extrusion and stretching, weaving, optional coating or lamination, printing, conversion, closure preparation, inspection and packing.

Strength Comes From a System, Not From One Number

Buyers sometimes focus on one specification, such as GSM, and assume that a heavier fabric automatically makes better Polypropylene Woven Sacks. In practice, performance comes from the interaction between fabric weight, tape denier, tape width, weave density, coating, seam construction, bag dimensions and filled-product behavior. A well-designed lighter sack may perform more reliably than a heavier sack with a weak seam or unsuitable dimensions. The body carries the load, the seam keeps the body closed, and the surface treatment keeps the pallet stable. Strength without balance is wasted strength.

VIDEPAK Reference Parameter	Published Range / Option	Why Buyers Should Care
Typical capacity	5–50 kg	Supports applications from smaller agricultural packs to heavy industrial sacks.
General grammage	About 80–150 GSM on the main product platform	Can be adjusted around load, handling severity and package geometry.
Published size range	Approximately 40 × 60 cm to 120 × 180 cm	Allows the package to be designed around bulk density rather than weight alone.
Fabric architecture	Flat or gusseted; coated or uncoated; optional liner	Changes volume, barrier performance, filling behavior and pallet shape.
Closure / bottom choices	Sewn, tape-over-sewn, heat-sealed and block-bottom options	Matches leakage control, automation and stacking requirements.

VIDEPAK’s published values are customizable product references rather than universal limits. Specific constructions can move outside these ranges according to application.

These options explain the broad application range. VIDEPAK positions Polypropylene Woven Sacks for grains, rice, sugar, flour, animal feed, fertilizer, resins, salt, minerals, sand, cementitious materials and other dry bulk products. A coarse pellet may need a very different structure from a fine powder; a sack stored indoors may need a very different UV package from one exposed outdoors. Same polypropylene family. Different job. Different specification.

Polypropylene Woven Valve Sacks: Designed Around Faster, Cleaner Filling

If standard Polypropylene Woven Sacks are a flexible packaging platform, Polypropylene Woven Valve Sacks take that platform one step closer to automated industrial filling. Instead of leaving the entire top open, a valve sack uses a smaller filling opening, normally located near a corner. The filling nozzle enters the valve, product flows into the bag, and the valve construction helps close or contain the opening after filling. VIDEPAK offers valve solutions for powders and granules used in construction materials, food-related dry products, chemicals and other industrial markets.

This changes the rhythm of the packing line. Open-mouth Polypropylene Woven Sacks normally require a separate post-fill closure step such as sewing or sealing. Polypropylene Woven Valve Sacks can reduce that handling because the valve is designed as part of the filling and closure system. For fine powders, the sack can also incorporate controlled micro-perforation so displaced air escapes during filling rather than turning the package into an unstable “pillow.” VIDEPAK lists micro-perforation, block bottoms, paper inserts, sonic sealing, tuck-in structures, polymer locking features and easy-opening solutions among its valve customization options.

The Valve Must Fit the Filler, Not Just the Artwork

The most important dimension on Polypropylene Woven Valve Sacks may not be the bag width or length. It may be the valve itself. Valve sleeve length, opening width, material, friction and sealing method need to work with the customer’s filling nozzle and product flow. A valve that is too tight can slow the machine. One that is too loose can create dust or leakage. A fine powder that carries a large amount of air requires different venting from dense granules. For that reason, VIDEPAK’s valve design is offered as a configurable system rather than one universal construction.

Block-bottom architecture can further change performance. A flatter rectangular base helps filled Polypropylene Woven Valve Sacks form a more brick-like shape, supporting upright stability and efficient pallet geometry. For cement, dry mortar, mineral powders and similar products, this combination of a woven load-bearing body, controlled venting, valve filling and block-bottom geometry can be especially useful when the customer’s priorities are speed, dust management and consistent stacking.

VIDEPAK’s current valve-bag product information states an annual capacity of more than 100 million valve bags and describes customization of printing, dimensions, thickness, bottom patterns and valve features. It also states that bulk orders commonly have a 15–25 business-day production lead-time reference, depending on order quantity and requirements. Because production schedules change, project-specific timing should always be reconfirmed when an order is placed.

BOPP Polypropylene Woven Sacks: When Industrial Strength Must Also Sell the Brand

Some packaging is seen only by warehouse teams. Other packaging has to survive the warehouse and then win attention in the market. BOPP Polypropylene Woven Sacks are designed for that second challenge. They combine a woven polypropylene fabric with a biaxially oriented polypropylene film surface. In simple terms, the woven layer carries the load; the BOPP layer carries the image. One protects the product mechanically. The other helps communicate the brand visually.

VIDEPAK’s BOPP Polypropylene Woven Sacks use laminated BOPP film to create a smoother printing surface than basic woven fabric. Reverse printing can place graphics beneath the outer film surface, helping protect the printed image from rubbing during filling, palletizing and distribution. VIDEPAK lists printing of up to 10 colors, along with glossy and matte appearances, allowing packaging designers to use photographs, detailed product information, strong brand colors and cleaner visual hierarchy.

Parameter for BOPP Polypropylene Woven Sacks	VIDEPAK Published Reference	Commercial Meaning
Thickness	90–130 microns	Selected around construction, load and handling needs.
Grammage	100–180 GSM	Supports different strength and presentation requirements.
Capacity	Optimized around 5–40 kg	Fits many agricultural, food-related and industrial retail packs.
Printing	Up to 10 colors	Supports detailed graphics and high visual differentiation.
Design options	Flat, gusseted, block bottom, matte, gloss, anti-slip, micro-perforated, transparent window	Lets engineering and marketing requirements share one package.

These are VIDEPAK product-page reference specifications and can be customized according to the individual project.

The beauty of BOPP Polypropylene Woven Sacks is not simply “better printing.” Their value lies in the combination. A laminated polymer face can improve external moisture resistance and surface cleanliness compared with an uncoated woven face; protected graphics can resist scuffing more effectively; a gusset can create a fuller rectangular package; micro-perforation can release trapped air; an anti-slip treatment can increase friction between filled sacks; and a transparent window can allow customers to see the packed product. More color, but also more control. Better appearance, but still a working industrial package.

There is also a useful material-design distinction. Because BOPP is itself polypropylene, BOPP Polypropylene Woven Sacks can be designed closer to a mono-polypropylene structure when the fabric, film, coating and other major components remain within the polypropylene family. That does not automatically make every finished sack recyclable everywhere: collection, inks, adhesives, closures and local processing systems still matter. Industry recycling guidance emphasizes that package recyclability depends on the complete design and the recycling system that actually exists in the destination market.

Paper Laminated Polypropylene Woven Sacks: A Paper-First Look With a Woven Backbone

Paper Laminated Polypropylene Woven Sacks solve a different branding and handling problem. Instead of putting BOPP film on the outside of the woven structure, these sacks combine an outer kraft paper face with woven polypropylene fabric, generally using a polyolefin lamination or tie layer to create the composite. An optional inner PE liner can be incorporated when additional dust, moisture, oil or product-isolation performance is needed.

The contrast with BOPP Polypropylene Woven Sacks is important. BOPP presents a smooth, polished, highly graphic film surface. Paper Laminated Polypropylene Woven Sacks present the more natural texture and visual language of kraft paper. Yet underneath that paper face remains woven polypropylene, giving the sack a mechanical backbone designed for tougher handling than the outer appearance alone might suggest. Paper on the outside, woven strength on the inside: appearance and engineering working in parallel.

Typical Component	Reference Commercial Range	Function in Paper Laminated Polypropylene Woven Sacks
PP tape width	About 2.5–3.2 mm	Influences weave structure, fabric behavior and sifting resistance.
Woven PP fabric mass	About 60–120 GSM; often 75–110 GSM in paper hybrids	Forms the primary load-bearing layer.
Lamination / tie layer	About 20–40 μm	Bonds the paper face to the woven structure and influences barrier behavior.
Kraft paper grammage	Commonly about 60–120 GSM	Controls paper stiffness, print appearance and surface feel.
Optional PE liner	Often about 15–30 μm	Adds another barrier against moisture, dust, oil or contamination where required.

The ranges above are representative commercial starting points published in VIDEPAK’s technical discussion of laminated woven sacks; final values depend on product density, filling method, transport and climate.

Natural brown kraft can give Paper Laminated Polypropylene Woven Sacks a traditional industrial or agricultural character, while white kraft can provide a cleaner background for detailed graphics and product information. PE-coated paper may also be considered when the outer structure requires stronger moisture or grease control. These choices allow the same broad product family to move from a practical industrial appearance to a cleaner premium-paper presentation without removing the woven PP reinforcement underneath.

Surface friction is another practical reason to select Paper Laminated Polypropylene Woven Sacks. A kraft-paper face naturally behaves differently from a smooth film surface and can support stable pallet handling, although actual stack behavior must still be validated with the filled product and pallet pattern. This makes Paper Laminated Polypropylene Woven Sacks attractive for minerals, building materials, chemicals, masterbatch, feed, seed and other dry products where the customer wants a paper-oriented appearance without giving up the reinforcement of woven polypropylene.

How to Choose Between Polypropylene Woven Sacks, Polypropylene Woven Valve Sacks, BOPP Polypropylene Woven Sacks and Paper Laminated Polypropylene Woven Sacks

The best way to compare these four families is not to ask which one is “premium” and which one is “basic.” Their advantages point in different directions. Plain Polypropylene Woven Sacks prioritize flexible structural design and cost-efficient performance. Polypropylene Woven Valve Sacks prioritize the relationship between filling efficiency, venting and closure. BOPP Polypropylene Woven Sacks add a high-impact branded face. Paper Laminated Polypropylene Woven Sacks combine a kraft-paper identity with woven reinforcement. The right choice follows the product journey.

Decision Factor	Polypropylene Woven Sacks	Polypropylene Woven Valve Sacks	BOPP Polypropylene Woven Sacks	Paper Laminated Polypropylene Woven Sacks
Main advantage	Versatile woven strength	Efficient valve filling	Branding plus woven strength	Paper appearance plus woven reinforcement
Print character	Functional to moderate	Depends on surface construction	High-detail, vivid, matte or gloss	Natural or clean kraft-paper presentation
Best filling logic	Open-mouth or customized	Automated or semi-automated valve lines	SOM, valve, PBOM or block-bottom formats	SOM, valve, pasted, pinch-bottom or block-bottom formats
Typical buying priority	Strength, flexibility and value	Speed, dust control and line compatibility	Shelf impact, scuff protection and differentiation	Paper feel, friction and industrial visual identity
Common product direction	Grain, feed, fertilizer, resin, salt and general dry goods	Powders, minerals, cementitious goods and granules	Branded food-related, feed, seed, fertilizer and agricultural goods	Minerals, chemicals, feed, seed and building materials

The comparison reflects the structural and application differences described in VIDEPAK’s current product and technical materials.

For a straightforward grain or feed application, conventional Polypropylene Woven Sacks may provide the cleanest balance between performance and cost. For a fine powder entering an automated filling line, Polypropylene Woven Valve Sacks may solve the more important problem: controlled filling and closure. When retail presentation and high-resolution graphics drive value, BOPP Polypropylene Woven Sacks move forward. When the brand wants kraft-paper character, greater natural surface friction and woven reinforcement, Paper Laminated Polypropylene Woven Sacks deserve close attention.

From Resin to Shipment: How VIDEPAK Builds a Complete Woven Packaging Solution

VIDEPAK’s role is not limited to offering four bag names in a catalog. Its value is the ability to connect material, conversion, printing, filling requirements and quality control across Polypropylene Woven Sacks, Polypropylene Woven Valve Sacks, BOPP Polypropylene Woven Sacks and Paper Laminated Polypropylene Woven Sacks. The company’s current website states that it was founded in 2008, employs more than 500 people, exports to more than 70 countries and has production capability of up to 800 million pieces annually across its broader heavy-duty bag portfolio.

For the woven product platform, VIDEPAK states that it uses 100% virgin polypropylene and performs incoming-material sampling before production. Its published quality-control approach covers checks related to material integrity, dimensions, tensile properties, impact behavior and UV weather resistance where applicable. Product pages also state that its production and testing system uses relevant ISO, ASTM, EN and JIS requirements according to the product specification. For buyers, the practical point is simple: a specification should become a repeatable manufacturing target, not remain an attractive drawing.

Testing is equally important because bags live outside laboratory conditions. A finished sack can experience dropping, vibration, compression, dragging, humidity and repeated handling. ISO standards for packaging recognize filled-package drop testing as a meaningful way to evaluate the effect of vertical impact, while ISO 23560 sets general characteristics, requirements and test methods for relevant woven PP food sacks. VIDEPAK’s own technical materials describe seam or weld checks, filled-bag drop validation, dust-leak observations, UV testing where required and dimensional inspection as parts of a risk-based quality approach.

Samples can then turn specifications into evidence. VIDEPAK currently offers reference samples for general material and workmanship review and custom mock-up samples produced around a customer’s intended dimensions, material structure, printing and special features. A custom sample is especially useful when the project involves new Polypropylene Woven Valve Sacks, complicated artwork for BOPP Polypropylene Woven Sacks, or a new layer structure for Paper Laminated Polypropylene Woven Sacks, because important details can be checked before full-scale production.

The final purchasing decision therefore should not be reduced to price per sack. A lower-priced package that slows a filler, leaks powder, shifts on pallets, damages graphics or requires repacking may create a higher total cost. A better-designed sack can support smoother production, cleaner logistics and stronger presentation. This is particularly important because coating, liners, valves, anti-slip treatments, block bottoms and premium printing each solve different failure modes; adding every feature is unnecessary, but ignoring the right feature can be expensive.

That is the central idea behind VIDEPAK’s woven packaging portfolio. Choose Polypropylene Woven Sacks when versatile woven strength and broad customization lead the decision. Choose Polypropylene Woven Valve Sacks when the filling process, dust management and closure efficiency lead the decision. Choose BOPP Polypropylene Woven Sacks when the package must travel like an industrial sack but communicate like branded packaging. Choose Paper Laminated Polypropylene Woven Sacks when kraft-paper character, handling friction and woven reinforcement need to work together.

What Are Polypropylene Woven Bags?

Polypropylene Woven Bags are robust, lightweight industrial packages engineered from flat, stretched polypropylene (PP) tapes woven into fabric and then converted into sacks. In everyday trade they appear under several aliases—raffia bags, woven PP sacks, block‑bottom woven sacks, BOPP‑laminated PP woven bags, and PP valve sacks—yet the underlying architecture remains the same: oriented polymer tapes interlaced to create a high‑strength textile that can be sewn, taped, or welded into dependable bulk containers. What makes Polypropylene Woven Bags stand out is their balance of strength‑to‑weight, tear resistance along warp and weft, puncture tolerance, and compatibility with fast, automated filling.

Features at a glance. The mechanical profile of Polypropylene Woven Bags is defined by high burst strength (a function of oriented tapes), controlled elongation, excellent seam retention, and a forgiving impact response. Coated versions offer moisture resistance; BOPP‑laminated versions deliver high‑fidelity graphics and surface stiffness; micro‑perforated options permit venting; UV‑stabilized grades endure sun exposure; antiskid treatments aid pallet stability. The result: a package that travels well, stacks cleanly, and arrives intact.

How they are made. The typical manufacturing route for Polypropylene Woven Bags runs as follows: resin pellets → tape extrusion and stretching (to orient molecules and increase tensile properties) → weaving on circular or flat looms → optional extrusion coating or BOPP lamination → printing (flexographic or reverse on BOPP) → cutting and gusseting → forming into open‑mouth or valve formats → mouth closure (sewing, tape‑over‑sew, heat sealing, or hot‑air welding) → inspection, counting, and palletization. Each step shapes the downstream behavior of the bag—strength, sealability, machinability.

Where they are used. Across supply chains, Polypropylene Woven Bags carry cement, dry mortar, white cement, fertilizers, grains, rice, sugar, flour, animal feed, industrial minerals, resins, salt, sand for flood control, and horticulture substrates. If the product is a free‑flowing solid between 5 and 50 kg, there is a strong chance it already rides in Polypropylene Woven Bags.

References (Selected, Non‑CNC)

1. ISO 23560:2015 — Packaging — Sacks made from polypropylene woven fabrics — Requirements and test methods.
2. FDA 21 CFR 177.1520 — Olefin polymers (polypropylene) for food‑contact applications.
3. FSSC 22000 Scheme — Packaging manufacturing scope for hygiene and food safety management.
4. Starlinger AD*STAR® technical brochures — Block‑bottom, hot‑air welded woven PP valve bags.
5. Statec Binder application notes — Over‑tape sealing and valve‑bag filling systems for woven PP sacks.
6. Supplier specifications (Made‑in‑China / Alibaba Global) — Typical ranges for mesh, GSM, BOPP film thickness, UV stabilization, and liner gauges for Polypropylene Woven Bags.
